By Michael Harris — Senior Product Engineer, TJJ Trade | Updated March 2026
Are you sourcing heavy-duty, compliant cast iron drain cover and frame sets for municipal, commercial, or residential projects? As an import manager or wholesaler, you need products that meet US load standards, withstand traffic loads, and fit your budget. With over 20 years of foundry expertise, TJJ Trade offers factory-direct cast iron drain covers and frames backed by ISO 9001 quality management, full OEM/ODM support, and reliable shipping to the USA. This guide covers everything you need to evaluate—technical specs, compliance, customization, and logistics—so you can source with confidence.
Why Procurement Professionals Choose Cast Iron Drain Covers and Frames
Import managers and brand owners face recurring sourcing pains: inconsistent quality from different suppliers, long lead times, hidden fees, and products that fail US compliance checks. A cast iron drain cover that cracks under a truck load or a frame that rusts within a year can damage your reputation and trigger costly replacements.
At TJJ Trade, we turn those pain points into peace of mind. Our cast iron drain cover and frame solutions are engineered to meet ASTM A48 Class 30B gray iron specifications—a standard widely recognized across North America for structural strength and durability. We offer load-rated designs ranging from pedestrian (EN 124 A15) to heavy traffic (EN 124 D400 / H20-H25 to AASHTO M306), so you get exactly the right product for your application.
Switching to a reliable factory-direct partner like TJJ Trade means you eliminate the middleman, gain direct quality control, and access a supply chain optimized for US-bound orders. No surprises—just consistent, compliant cast iron drainage solutions.
Product Highlights and Technical Specifications
Every cast iron drain cover and frame we produce is made from virgin pig iron and scrap steel in our foundry using green sand molding and precision machining. This ensures consistent metallurgy, tight tolerances, and a long service life. Below are the most requested specifications for US buyers.
| Parameter | Typical Value / Range | Notes |
|---|---|---|
| Material | Gray cast iron (ASTM A48 Class 30B/35B) | Ductile iron (ASTM A536) available on request |
| Load Rating | A15 (pedestrian) · B125 (light traffic) · C250 (driveways) · D400 (roadways) · E600 (industrial) | Per EN 124 / AASHTO M306 / H20-H25 |
| Cover Dimensions | Round: 6"–48" · Square/Rectangular: up to 60"×48" | Custom sizes supported |
| Frame Depth | 1.5" – 6" | Adjustable for pavement thickness |
| Surface Finish | As-cast · painted (bitumen / epoxy / galvanized) | Custom colors available |
| Anti-theft Feature | Bolted covers · tamper-proof screws · key-lock systems | Standard or custom |
| Grate Options | Solid · slotted · heel-proof · mesh | Per project requirement |
| Certifications | ISO 9001:2015 · ASTM A48 · EN 124 · AASHTO M306 | Supporting test reports available |
cast iron drain cover sizes cast iron covers cast iron stove cover factory
*All parameters are typical for standard products. Final specifications to be confirmed in the order contract.
Compliance and Certification for the US Market
Compliance is non-negotiable when sourcing construction and infrastructure components for the US. Our cast iron drain cover and frame products are manufactured under ISO 9001:2015 certified processes, and we routinely supply third-party material test reports (MTR) showing chemical composition and physical properties. For road and highway applications, our load-rated covers meet or exceed the requirements of AASHTO M306 (Standard Specification for Manhole Frames and Covers) and are designed to handle HS20 and HS25 wheel loads.
For building and landscape drainage—such as park pathways, parking lots, and residential access—our light-duty and medium-duty covers conform to ASTM A48 and EN 124, ensuring they will not deform or break under intended use. If your project requires specific local codes (e.g., Los Angeles City, DOT standards in Texas or Florida), we invite you to share the code references. Our engineering team will confirm compliance before production.
We do not make false claims of UL, FM, or NSF certification unless explicitly listed per order. Please request specific certifications during the inquiry stage and we will advise on feasibility.
OEM/ODM Customization to Fit Your Brand
One of the strongest advantages of sourcing from TJJ Trade is our in-house mold making and pattern shop. We have produced custom cast iron drain cover and frame sets for hundreds of clients in the US, South America, Europe, and Africa. Customization options include:
- Branding – Cast your company logo, project name, or unique serial number directly into the cover surface.
- Custom sizes & geometry – Non-standard diameters, frames with angled flanges, recessed covers for flush installation with brick or concrete.
- Anti-theft modifications – Proprietary bolt patterns, special tool requirements, or internal locking rings.
- Color & coating – Epoxy powder coating (RAL/color-matched), hot-dip galvanizing, or classic bitumen black.
- Packaging – Poly-wrapped, strapped pallets, or custom crating for mixed orders.
OEM lead time: First sample generally 15–20 working days after drawing approval. Mass production 25–40 days depending on quantity.
Cast Iron vs. Alternative Materials: A Comparative Analysis
When evaluating drain covers, buyers often compare cast iron with steel, ductile iron, and polymer composites. The table below summarizes key differences relevant to US B2B procurement:
| Property | Cast Iron (Gray) | Ductile Iron | Fabricated Steel | Polymer Composite |
|---|---|---|---|---|
| Tensile Strength | 30–35 ksi (207–241 MPa) | 60–80 ksi (414–552 MPa) | 50–70 ksi (345–483 MPa) | 8–12 ksi (55–83 MPa) |
| Corrosion Resistance | Good (with coating) | Good (with coating) | Moderate (needs galvanizing) | Excellent (inherent) |
| Ductility | Low (brittle) | High | High | Low |
| Weight (for same size) | Heavy (typically 120–200 lbs) | Slightly lighter (~10% less) | Lighter (~40% less) | Light (up to 70% less) |
| Recyclability | 100% recyclable | 100% recyclable | 100% recyclable | Limited |
| Anti-theft Value | Low scrap value (less theft) | Moderate scrap value | High scrap value (targeted) | Near-zero scrap value |
| Typical Service Life | 30–50 years (with coating) | 40–60 years | 15–30 years (coating dependent) | 10–25 years (UV degradation possible) |
| Cost per Unit (estimate) | $$ (moderate) | $$$$ (higher) | $$$ (variable) | $ (low) |
For projects requiring a balance of durability, life cycle cost, and security against theft, gray cast iron remains the most widely specified material in US infrastructure. Ductile iron is preferred for high-impact or seismic zones, while polymer composites suit light-duty decorative drainage—but many US governmental bodies still mandate cast iron for road and traffic areas.
Real-World Applications Across Sectors
Our cast iron drain cover and frame products have been installed in diverse environments across the United States and abroad. Common use cases include:
- Municipal stormwater drainage – Roadway catch basins, curb inlets, and manhole access covers meeting DOT specifications.
- Commercial parking lots & garages – Heavy-duty D400 covers for vehicle traffic lanes.
- Parks, plazas & pedestrian zones – Recessed covers that accept brick or concrete infill for flush finishes.
- Industrial facilities & loading docks – E600-rated covers for fork truck and heavy machinery loads.
- Residential driveways & estates – Decorative cast iron drainage grates with ornamental patterns.
- Water & wastewater treatment – Corrosion-resistant coated covers for chemical environments.
If you have a specific application in mind, our engineering team can review the project load requirements and drainage flow rates to match the correct frame and grate design.
What Our Clients Say About Their Cast Iron Drain Covers and Frames
Our Foundry: 20+ Years of Casting Excellence
Shijiazhuang TJJ Trade Co., Ltd. operates a modern foundry in Hebei Province, China, that has been producing cast iron products for over two decades. It stands as one of the early casting factories in China, with a team of experienced workers and management dedicated to consistent quality. Our facility covers 12,000 square meters and employs more than 80 skilled foundry professionals, engineers, and QC staff.
Our quality management system is ISO 9001:2015 certified, and we have supplied cast iron drain covers and frames to buyers in the USA, South America, Europe, and Africa. We invite you to arrange a virtual tour or request a video of our casting line during the inquiry stage.
Pricing, MOQ, Lead Time, and Logistics
- MOQ (Minimum Order Quantity): 50–100 pieces per model number (mixed sizes welcome in one container). For trial orders, we can accommodate smaller quantities with adjusted unit pricing.
- Lead Time: 20–35 days from sample approval and deposit receipt. OEM first sample 15–20 working days. Express shipping via air available for urgent samples (5–7 days).
- Pricing Terms: FOB Tianjin or CIF to major US ports (Los Angeles, Long Beach, Houston, Savannah, New York/Newark). We will provide a complete cost breakdown including inland transport, port fees, and ocean freight.
- Payment: T/T (30% deposit, 70% balance before shipment or against BL copy). L/C at sight also supported for qualifying orders.
- Packaging: Each drain cover and frame unit is poly-wrapped, stacked on heavy-duty pallets, strapped, and labeled with part number, quantity, and customer mark. Crating available for irregular or fragile parts.
- After-Sales: We provide pre-shipment photos and inspection reports (including video call QC if requested). Any issue with the product upon arrival—shipment, damage, or defect—we respond within 24 hours and work to a fair resolution per the contract.
*All lead times, MOQ, and pricing are indicative and subject to order contract. Final commercial terms to be confirmed in the sale agreement.
Start Your Sourcing Project Today
Whether you need a standard cast iron drain cover and frame for inventory or a custom-designed set for a municipal tender, we invite you to share your requirements. Our team of engineers and trade specialists will respond with a technical recommendation, quote, and lead time within 48 hours.
